Specification
| Mode |
12 Slots RACK |
| Size(mm) L*W*H |
800*651*1430 mm |
| Single slot size |
240*300*320mm |
| Overall max power |
15kW |
| Single box max power |
1300W |
| Input Voltage range |
150Vac~280Vac |
| Max input current |
≤69A |
| Battery type |
72V Li-ion |
| Charging voltage |
|
| Max charging current |
15A(max) |
| Battery exchange mode |
Manual Swapping |
| Working Temperature |
0 – 50℃ |
| Working Humidity |
10% – 85% |
| Storage temp. |
-10 – 65℃ |
| Waterproof |
IP20 |
| Charge method |
Manual Swapping |
| Charging cable Hot-plug life |
≤5000 times |
| Slots quantity |
12slots |
| Communication mode |
CAN2.0B
|
Features
1. Fast Battery Swapping for Maximum Uptime
This battery swapping cabinet enables instant battery replacement within minutes, helping electric motorcycle fleets eliminate long charging time and significantly improve daily operational efficiency.
2. 12-Slot High-Capacity Design
Designed with 12 independent charging slots, the system supports continuous battery rotation, making it ideal for battery swap stations serving delivery riders and fleet operators.
3. 15kW High-Power Charging Performance
With up to 15kW input power, the cabinet delivers stable and efficient charging, ensuring a constant supply of fully charged batteries for high-demand usage scenarios.
4. Smart CAN Communication System
Integrated CAN communication enables real-time data exchange between battery and cabinet, providing intelligent charging control and enhanced system safety.
5. Advanced Safety Protection System
This battery swap cabinet is equipped with multiple protection features, including over-current, short circuit, over-temperature, and smoke detection, ensuring safe and reliable operation.
6. Durable Industrial-Grade Structure
Built with high-strength steel, the cabinet is designed for long-term use in outdoor and semi-outdoor battery swapping stations, especially in demanding environments.
7. Intelligent Thermal Management
The built-in cooling system with automatic temperature control ensures stable performance and extends equipment lifespan.
8. Flexible Deployment for EV Battery Swap Stations
The modular design allows easy installation in various scenarios, including electric scooter charging stations, delivery hubs, and urban mobility networks.
