| No. | Item | Parameter | Remark |
| 1 | Nominal Voltage | 51.2V | |
| 2 | Nominal Capacity | 25Ah | |
| 3 | Standard charging current | 12.5A(0.5C) | |
| 4 | Maximum charging current | 12.5A | |
| 5 | Charge cut-off voltage | 58.4V | Battery cell: 3.65 V |
| 6 | Standard discharge current | 12.5A(0.5C) | |
| 7 | Maximum continuous current | 50A(2C) | |
| 8 | Discharge cut-off voltage | 40V | Battery cells: 2.5V |
| 9 | Charging temperature | 0~55 ℃ | |
| 10 | Discharge temperature | -20~60 ℃ | |
| 11 | Working humidity | ≤85%RH | |
| 12 | Battery weight | ≈11.5kg | |
| 13 | Protection Level | IP65 | |
| 14 | Dimensions | 180×155×280mm | |
| 13 | Normal temperature cycle life | 1500 times
standard charge and discharge @25±2℃&90±5kPa preload conditions, capacity retention (SOH) = 80% |
|
Standard Battery Pack Size:Meets the power requirements of over 90% of various vehicle types, offering wide compatibility for diverse applications.
Unique Battery Box Design:Lightweight, compact, and easy to install, streamlining the setup process for operational efficiency.
National Standard Socket & 2+6 Battery Swapping Interface:Equipped with the latest national standard socket and a versatile battery swapping interface for seamless integration and flexibility.
High Protection Rating (IP67):Offers robust protection against dust and water, ensuring reliable performance even in challenging environments.
GPS + Beidou Dual Positioning & 4G Communication:Supports advanced GPS + Beidou dual positioning and 4G connectivity for real-time tracking and remote communication capabilities.
Extended Cycle Life:Built to endure over 1500 charge cycles, ensuring long-term use and minimizing maintenance needs.
Battery Indicator & USB TYPE-C Interface:Includes a clear battery indicator light and a USB TYPE-C output interface, enabling charging of mobile phones, laptops, and other electronic devices for added convenience.
