Specification
| Mode |
5 Slots |
| Size(mm) L*W*H |
1800*600*600 |
| Single slot size |
280*200*400mm |
| Overall max power |
7kw |
| Single box max power |
1320w |
| Input Voltage range |
150Vac~270Vac
47HZ-63HZ |
| Max input current |
≤38A |
| Battery type |
72V Li-ion |
| Charging voltage |
52V~88V |
| Max charging current |
15A |
| Battery exchange mode |
RFID card |
| Working Temperature |
0 – 45℃ |
| Working Humidity |
10% – 85% |
| Storage temp. |
-20 – 70℃ |
| Communication network |
4G (Compatible 2G) |
| Waterproof |
IP54 |
| Charge method |
Smart charging |
| Charging cable Hot-plug life |
≥3000 times |
| Slots quantity |
5 slots |
| Communication mode |
CAN2.0B |
FEATURES
1.Swap batteries in about 1 minute, solving long charging wait times for electric motorcycles in Africa and boosting delivery fleet productivity；
2.Real-time battery voltage, current, and SOC monitoring; smart charging management extends battery life and reduces maintenance costs
3.4G IoT connectivity allows operators to remotely monitor swap station status, optimize battery inventory, and manage fleet operations。
4.Equipped with short-circuit, reverse-polarity, over-temperature, smoke, and leakage protections for rider and equipment safety
5.Compatible with 72V lithium-ion batteries, supports RFID card and mobile app operation, ideal for delivery, logistics, and shared e-mobility applications。
6. Smart battery swap system ensures 24/7 battery availability, increases fleet uptime, and reduces energy and maintenance costs
