| Item |
Spec. |
Item |
Spec. |
| Model / Version |
T-9 / PG1200 |
Climbing Ability |
8° |
| Vehicle Dimensions |
1745*770*1170 mm |
Controller |
12-Tube 35A |
| Wheelbase |
1255 mm |
Charger |
72V 10A |
| Seat Height |
773 mm |
Charging Time |
2-4 hours |
| Ground Clearance |
760 mm |
Charging Port / Connector Type |
IEC 60320 C13 / Chogori KR2+6 |
| Curb Weight |
102 kg |
Brake System |
Hydraulic Disc Brake |
| Max Load Capacity |
300kg |
Suspension / Shock Absorbers |
Front: Hydraulic damping
Rear: Hydraulic shock absorber |
| Passenger Capacity |
2 |
Tyres / Rims |
Front: 3.0-10inch Rear: 3.0-10inch
Forged Steel Rims |
| Motor Type |
HUB motor PMSM |
Display |
LED screen |
| Motor Power |
1200W |
Lights |
12VLED |
| Peak Motor Power |
2000W |
Waterproof Rating |
IP67 |
| Rated Voltage |
76.8V |
Security Features |
Security Alarm / Remote control |
| Battery Compatibility |
72V 30-40Ah Lithium Battery |
Riding Modes |
3 speeds |
| BMS Type |
CAN + 4G Smart BMS |
Reverse Gear |
Yes |
| Battery Cycle Life |
2000 cycle @70% |
Spare Parts Availability |
Yes |
| Removable or Fixed Battery |
Removable |
Certifications |
China CCC |
| Range |
70-90 km |
Packing Method |
Steel Frame + Carton |
| Max Speed |
60km/H |
Container Loading Quantity |
Around 70 pcs |
Features
1200W High-Performance Motor ：2000W peak power and 60 km/h top speed
300 kg Heavy Payload：Ideal for two passengers and cargo delivery
70–90 km Long Range：Removable 72V lithium battery with fast charging
CAN + 4G Smart BMS：Real-time battery monitoring and fleet management
Reliable & Durable Design：Hydraulic suspension, disc brakes, IP67 waterproof motor
