Specification
| Item |
Specification |
| Model |
PG-6 |
| Vehicle Dimensions |
1980 × 690 × 1050 mm |
| Wheelbase |
1320 mm |
| Seat Height |
820 mm |
| Ground Clearance |
250 mm |
| Motor Type |
QS DC Rear Hub Brushless Motor |
| Rated Motor Power |
72 V / 3000 W |
| Controller |
FARDRIVER 72 V FOC Controller |
| Battery Specification |
72 V 45 Ah, LFP |
| Charger |
10 A Smart Power Cut-off Charger |
| Charging Time |
4–5 h |
| Max. Speed |
85 km/h |
| Range |
80–90 km |
| Climbing Ability |
≥22° |
| Max. Load Capacity |
250 kg |
| Net Weight |
110 kg |
| Gross Weight |
135 kg |
| Brake System |
Disc Brake + Electromagnetic Brake + Power Cut-off / Mechanical + Electronic |
| Suspension |
Front: Hydraulic Damping Shock Absorber / Rear: Dual Spring Shock Absorber |
| Tires |
Front: 2.75-18 / Rear: 110/90-16; Tubeless |
| Wheels |
Front: Solid Aluminum Wheel |
| Display |
LCD |
| Headlight |
Oversized LED Headlight |
| Riding Modes |
3 Gears + Reverse + P |
| Frame / Body |
Steel |
| Packing Method |
Iron Stand + 7-layer Carton |
| Container Loading Quantity |
CKD: 150 units/40HQ ;SKD: 105 units/40HQ; CBU :48 units/40HQ |
| Climbing Speed |
≥35 km/h |
| Rated Load Capacity |
100 kg |
| Saddle |
Four-layer Elastic Leather + High-elasticity Foam |
Features
1. 3000W Rear Hub Motor with 85 km/h Top Speed
Powered by a 3,000W QS rear hub motor and Fardriver FOC controller, the MK-XN delivers a top speed of up to 85 km/h, providing responsive and stable performance for daily commuting, delivery and commercial mobility.
2. 250 mm Ground Clearance for Challenging Roads
With an impressive 250 mm minimum ground clearance, the motorcycle is designed to handle potholes, uneven pavement, speed bumps and unpaved roads more confidently — making it particularly suitable for road conditions in Africa and Latin America.
3. 250 kg Maximum Loading Capacity
A reinforced steel frame supports up to 250 kg maximum loading capacity, providing practical carrying capability for riders, passengers, delivery boxes and everyday cargo.
4.72V 45Ah LFP Battery
The 72V 45Ah lithium iron phosphate battery delivers approximately 80–90 km riding range, combining reliable daily performance with the safety and durability advantages of LFP battery technology.
5. Designed for Mixed Road Conditions
Large 2.75-18 front and 110/90-16 rear tubeless tires, front hydraulic damping suspension, dual rear spring shock absorbers and front/rear disc brakes provide improved stability, comfort and braking control across different road surfaces.
