Specification
| Item |
Spec. |
Item |
Spec. |
| Model / Version |
Magician – PG1500 |
Controller |
12-Tube 40A |
| Vehicle Dimensions |
1958*718*1180 mm |
Climbing Ability |
8° |
| Wheelbase |
1385 mm |
Charger |
72V 10A |
| Seat Height |
773 mm |
Charging Time |
2-4 hours |
| Ground Clearance |
170 mm |
Charging Port / Connector Type |
IEC 60320 C13 / Chogori KR2+6 |
| Curb Weight |
94kg (44front/50rear)(without battery) |
Brake System |
CBS Combined Braking System with Disc Brake |
| Max Load Capacity |
300 kg |
Suspension / Shock Absorbers |
Front Hydraulic Damper, Rear 5-Level Adjustable Hydraulic Shock |
| Passenger Capacity |
2 |
Tyres / Rims |
Front: 90/90-12 inch Rear: 3.0-10 inch
Forged Steel Rims |
| Motor Type |
HUB motor PMSM |
Display |
LED screen |
| Motor Power |
1500W |
Lights |
12VLED |
| Peak Motor Power |
2458W |
Waterproof Rating |
IP67 |
| Rated Voltage |
76.8V |
Security Features |
Security Alarm / Remote control |
| Battery Compatibility |
72V 30-40Ah (LFP) |
Riding Modes |
3 speeds |
| BMS Type |
CAN + 4G Smart BMS |
Reverse Gear |
Yes |
| Battery Cycle Life |
2000 cycle @70% |
Spare Parts Availability |
Yes |
| Range |
70-90 km |
Packing Method |
Steel Frame + Carton |
| Max Speed |
63 km/h |
Optional colors: |
White/Gray/Black/Purple |
Features
Powerful 1500W Motor
High-efficiency PMSM hub motor with 2458W peak output, delivering smooth acceleration and a top speed of 63 km/h for urban commuting and commercial transportation.
Heavy-Duty 300 kg Payload
Robust chassis supports up to 300 kg, allowing two-passenger riding or heavy cargo transportation for delivery and fleet applications.
Smart Removable Lithium Battery
Compatible with 72V 30–40Ah LFP batteries, offering 70–90 km range, over 2,000 charge cycles, and intelligent battery management through CAN + 4G Smart BMS.
Safe & Comfortable Riding
Equipped with CBS combined braking, hydraulic suspension, adjustable rear shock absorbers, reverse gear and LED lighting for enhanced control and rider comfort.
Built for Commercial Operation
IP67 waterproof motor, anti-theft alarm, remote control and reliable spare parts support reduce maintenance costs and improve fleet efficiency.
