Specificaiton
| Model |
PG-3 |
| Rated Voltage |
72V |
| Rated Power |
4.0KW |
| Max Efficiency |
10.5KW |
| Battery capacity |
LFP 50AH |
| Recharge Cycles |
2000 |
| Charging Time |
15A 5h |
| Maximum Speed Km/h |
80km/h |
| Distance Range( Km) |
80⁓110 |
| Weight with Package(Kg) |
115Kg |
| Controller |
160A |
| Rear shock absorbers |
Hydraulic twin-spring |
| FR&RR Tyres |
FR:80/90-17; RR:100/90-17 |
| wheelbase |
1390mm |
| FR Brakes |
Disc brake |
| RR Brakes |
Brake drum |
| Dimension(mm) |
2040×770×1050 |
| Battery size(mm) |
313×193×360 |
| Max load (Kg) |
220 |
| Motor type |
Mid Motor |
| Climbing degree |
≥30° |
| Rated Speed |
4800rpm |
| Peak Torque |
456.7N.m |
| Peak Speed |
8000rpm |
| Max Efficiency |
＞95% |
| Pole Pairs |
4 |
| Position Sensor |
Magnetic Binding |
| Temperature Sensor |
KTY83-122 |
| Insulation Class |
H |
| Protection Class |
IP67 |
| Transmission Type |
chain and sprocket drive |
| Cooling Method |
natural air cooling |
| Units/40HQ |
CKD:175units / SKD:105 units |
Features
1. Lower Cost. Higher Profit.
- Long-life LFP battery (2000+ cycles)
- Up to 110 km range per charge
- Significantly lower cost than fuel & lead-acid bikes
2. One Charge = One Working Day
- 72V 50Ah high-capacity battery
- 5-hour charging time
Reliable full-day operation for delivery & transport
3.Built for Heavy Load & Rough Roads
- Max load: 220 kg
- Climbing ability: ≥30°
- Hydraulic rear suspension
Stable performance on dirt roads and hills
4.Hot Climate Ready
- Operating temperature up to 50°C
- Motor heat resistance up to 180°C
No overheating, no performance drop
5. All-Weather Reliability
- IP67 waterproof & dustproof
Works in rain, mud, and harsh environments
6. Strong Performance
- Peak power: 10.5 kW
- Torque: 456.7 N·m
- Max speed: 80 km/h
More power for more jobs every day
Ideal For
- Delivery & logistics
- Passenger transport
- Cargo & daily commuting
