Specification
| Model |
PG-9 |
| Rated power（kw） |
4 |
| Peak Power（kw） |
10 |
| Max. Torque（N.m /rpm） |
82 |
| Max. Speed（km/h） |
80 |
| Range（km） |
110 |
| Battery specification |
76V 45AH Li-ion |
| Number of batteries |
1 |
| Battery weight（kg/block） |
24 |
| Recharger |
72V_10A/20A |
| Charge times（h） |
6~6.5h（10A）/3~3.5h（20A） |
| Controller |
YCK072120A |
| Climbing Ability（°） |
26° |
| Brake system (front / rear) |
disc brake/disc brake |
| Tire Size (Front/Rear) |
Front：80/90-17 / Rear：100/80-17 |
| Wheel Type |
Aluminum |
| Product Dimensions（mm） |
2080×790×1100 |
| Wheelbase（mm） |
1350 |
| Seat Hight（mm） |
790 |
| Min. Ground Clearance（mm） |
200 |
| Vertical wading depth （mm） |
400 |
| Net weight （kg） |
127 |
| Total load（kg） |
150 |
| Headlight |
LED |
| Signal Light |
LED |
| Tail Light |
LED |
| License plate light |
LED |
| Meter |
LED |
| Other configuration |
USB |
Features
4kW Rated Power, 10kW Peak Power
Strong acceleration and responsive performance with 4kW rated power, 10kW peak power and 82 N·m maximum torque.
Up to 110km Riding Range
The 76V 45Ah lithium-ion battery provides up to 110 km of range, supporting daily commuting and commercial mobility.
80km/h Top Speed
A maximum speed of 80 km/h provides efficient and practical performance for urban and intercity riding.
26° Climbing Capability
High torque and optimized power delivery enable PG-9 to handle slopes and challenging road conditions.
200mm Ground Clearance & 400mm Wading Depth
Designed for uneven roads, potholes, gravel surfaces and wet-road conditions, with 200 mm ground clearance and 400 mm vertical wading depth.
