Specification
| Item |
Spec. |
Item |
Spec. |
| Model / Version |
PG-Tank3000 |
Controller |
Large 18-tube 80A |
| Vehicle Dimensions |
1930x770x1180 |
Charger |
72V 10A |
| Wheelbase |
1355 mm |
Charging Time |
2-4 hours |
| Seat Height |
780 mm |
Charging Port / Connector Type |
IEC 60320 C13 / Chogori KR2+6 |
| Ground Clearance |
145 mm |
Brake System |
CBS Combined Braking System with Disc Brake |
| Curb Weight |
157 kg |
Suspension / Shock Absorbers |
Front: Upright hydraulic damping shock absorption
Rear: Adjustable rear shock absorption |
| Max Load Capacity |
350 kg |
Tyres / Rims |
Front: 120/70-12inch
Rear: 130/70-12inch
Forged Steel Rims |
| Passenger Capacity |
2 |
Display |
LED screen |
| Motor Type |
HUB motor PMSM |
Lights |
12VLED |
| Motor Power |
72V/3000W |
Waterproof Rating |
IP67 |
| Peak Motor Power |
4500W |
Frame / Body |
Fuel motorcycle-grade frame |
| Rated Voltage |
76.8V |
Security Features |
Security Alarm / Remote control |
| Battery Compatibility |
72V 30-40Ah(LFP) |
Riding Modes |
3 speeds |
| BMS Type |
CAN + 4G Smart BMS |
Reverse Gear |
Yes |
| Battery Cycle Life |
2000 cycle @70% |
Spare Parts Availability |
Yes |
| Range |
70-90 km |
Packing Method |
Steel Frame + Carton |
| Max Speed |
85km/h |
Container Loading Quantity |
Around 65 pcs |
| Climbing Ability |
10° |
Optional colors |
White/Gray/Black/Red |
Features
1. Powerful Performance for Diverse Road Conditions
3000W Rated Motor | 4500W Peak Power | 85 km/h Top Speed
2.Heavy-Duty Design for Commercial Operations
350 kg Payload | Motorcycle-Grade Frame
3.Lower Operating Cost with Long-Life LFP Battery
72V Lithium Iron Phosphate Battery | 2000+ Cycles
4.Smart Fleet Management with CAN + 4G BMS
5. Built for Challenging Roads
Hydraulic Suspension | CBS Disc Braking | IP67 Protection
