| Item |
SPECIFICATION |
| Model |
PG-5 |
| Vehicle size（mm) |
2070X800X1150mm |
| Wheelbase（mm) |
1480mm |
| Seat cushion height（mm） |
835mm |
Min. ground clearance
（mm) |
150mm |
| Max.Speed（km/h) |
100km/h |
| Climbing degree |
≥22° |
| Gear |
1/2/3/R/P |
| Gear Definition |
I gear：Top speed:35km/h
II gear：Top speed:60km/h
III gear：Top speed:100km/h |
| Battery type |
LFP lithium optional |
| Battery capacity |
72-50Ah |
| Range |
≥200km（Dual batteries） |
| Charging time |
5-6h |
| Electric motor type |
QS 138 Mid-drive motor |
| Motor rate power |
72V5000W |
| Controller |
Fardriver24mos150A/400A |
| DC-DC converter |
Lihua EMC |
| Power loom |
Liu’s Waterproof Integrated Type |
| Head light |
LED |
| Turning light |
halogen bulb |
| Brake |
LBN FR&RR Disc.brake |
| Tire |
FR:3.00-17/RR:100/80-17; Tubeless, Yuanxing brand |
| Suspension |
Front hydraulic shock, ∅32mm front fork; Rear dual spring shock; Xinghuo brand |
| Display |
LCD VA |
| Rear rack |
Black large rear rack+ foot rest |
| Front bumper |
black |
| N.W |
133kg |
| G.W |
148kg |
| SKD Package size |
1870*440*850mm |
Features
1️⃣ 5000W Mid-Drive Power — Performance Equal to a 150cc Motorcycle
Powered by a 72V 5000W mid-drive motor, the drivetrain delivers much higher torque than hub motors by using chain transmission.
Even under full load, it maintains strong acceleration and can climb ≥22°, reaching performance comparable to a 125–150cc gasoline motorcycle.
2️⃣ Three-Gear Power Management — Designed for Commercial Use
Unlike normal electric motorcycles with only one power mode, this model features three intelligent driving gears:
- Gear I – High torque, low power for heavy load & hills
- Gear II – Optimized efficiency for city delivery
- Gear III – Full power, up to 100 km/h
This system significantly reduces battery stress, improves efficiency, and extends service life, making it ideal for delivery fleets and battery-swapping operations.
3️⃣ Dual 50Ah LFP Batteries — Long Life, High Safety, Perfect for Swapping
Equipped with dual 47Ah lithium iron phosphate (LFP) batteries, the vehicle offers a range of ≥170 km.
LFP technology provides:
- 3000+ charge cycles
- Excellent thermal stability
- Safe full charge and full discharge
- Ideal for high-frequency swapping and fast charging
This is the most reliable battery solution for commercial EV operations in hot climates.
4️⃣ 350kg Heavy-Duty Chassis — Built for Real-World Cargo
Designed with a 350 kg rated load, reinforced frame, long wheelbase and heavy-duty tubeless tires, the motorcycle easily carries:
Rider + batteries + cargo + delivery box
It performs reliably on rough roads, potholes, dirt tracks and speed bumps, making it perfect for Africa and other demanding markets.
5️⃣ Industrial-Grade Motor Control — Stable in Heat and Heavy Load
Using a Fardriver 18-MOSFET controller (300A peak) with waterproof integrated wiring, the system ensures:
- Stable power under high temperature
- No power drop under heavy load
- Strong protection for motor and battery
- Long-term reliability for commercial fleets
