Specification
| No. |
project |
Parameter |
remarks |
| 1 |
Nominal voltage |
62.9V |
|
| 2 |
Nominal capacity |
60Ah |
|
| 3 |
Maximum continuous charging current |
30A |
|
| 4 |
Charging voltage |
73.1V |
Cell: 4.3 V |
| 5 |
Max sustained discharge current |
80A |
Max peak discharge current: 120A,30S |
| 6 |
Discharge cutoff voltage |
51V |
Cell: 3 V; |
| 7 |
Charging temperature |
0~55℃ |
|
| 8 |
Discharge temperature |
-20~55℃ |
|
| 9 |
Work humidity |
15%~90%RH |
|
| 10 |
Weight |
About 18kg |
|
| 11 |
Cycle life |
1500 times |
Standard 25℃ charge-discharge cycle to 80% capacity, 100%DOD |
Features
Automotive-Grade A Class Cells： Safe and long-lasting with over 2,000 charge cycles.
Laser Welding + Cu-Al Busbars： Supports high continuous discharge current; improved conductivity and thermal performance
Optimized PCB Design： Isolated tab structure with enhanced vibration resistance, thermal management, and mechanical integrity.
4G + GPS/BeiDou + App Integration： Real-time remote monitoring and dual-mode positioning for security and fleet management.
12-Level Intelligent BMS Protection：Comprehensive safeguards: overcharge, over-discharge, short circuit, overheating, and more.
Aluminum-Magnesium Alloy Casing：Die-cast structure; heat-resistant (up to 1000°C), corrosion-resistant, impact-resistant.
IP67 Protection：Dustproof and waterproof; reliable performance in extreme weather and terrain.
