Specification
| NO. |
Item |
Parameter |
Remark |
| 1 |
Nominal Voltage |
73.8V |
|
| 2 |
Nominal Capacity |
60Ah |
|
| 3 |
Maximum continuous charge current |
30A |
|
| 4 |
Charge cut-off voltage |
86V |
Cell：4.3 V |
| 5 |
Maximum continuous discharge current |
90A |
Max peak discharge current:120A，30S |
| 6 |
Discharge cut-off voltage |
60V |
Cell：3 V； |
| 7 |
Charge temperature |
0~55℃ |
|
| 8 |
Discharge temperature |
-20~55℃ |
|
| 9 |
Working humidity |
15%~90%RH |
|
| 10 |
Weight |
Around 22kg |
|
| 11 |
Lifespan |
2000 cycles |
25℃ standard charge and discharge cycle to 80% capacity, 100% DOD |
| 12 |
Size |
231×180×317mm |
|
Features
High-Performance Battery Cells
Premium automotive-grade cells deliver stable power output and exceptional cycle life beyond 2,000 cycles.
Advanced Welding & Conductive Busbars
Precision laser welding paired with copper-aluminum busbars supports high discharge currents with reduced resistance and improved heat control.
Robust Circuit Board Engineering
Innovative PCB layout isolates critical pathways, boosting mechanical strength and thermal stability under demanding road conditions.
Intelligent Connectivity Suite
Integrated 4G, GPS/BeiDou, and mobile app functions provide continuous battery visibility, security alerts, and fleet-level management.
Multi-Layer BMS Safety System
A 12-stage intelligent protection framework guards against electrical and thermal hazards to ensure safe operation at all times.
Reinforced Alloy Enclosure
The aluminum–magnesium die-cast shell offers exceptional rigidity, corrosion resistance, and extreme-temperature endurance.
All-Terrain IP67 Durability
Built to withstand dust, rain, and rugged terrain for reliable use across diverse environments.
