Specification
| No. |
Item |
Parameters |
Remark |
| 1 |
Battery type |
NCM |
/ |
|
2 |
Working temperature |
Charging：0～55℃
Discharge ：-20～55℃ |
Do not charge below 0°C. |
| 3 |
Nominal capacity |
75Ah |
0.2C charge/0.2C discharge ，25±2℃ |
| 4 |
Configuration |
4 S 20 P |
/ |
| 5 |
Nominal Voltage |
73.4V |
Battery Cell Voltage：3.67V |
| 6 |
Working Voltage Range |
56~86.4V |
/ |
| 7 |
Nominal Discharge Current |
38A |
25±2℃ |
| 8 |
Nominal Charging Current |
38A |
25±2℃ |
|
9 |
Max continuous Charging current |
100A @10S |
High temperature rise at 2C discharge.
OTP activates after ~20 min at 25°C. |
| 10 |
Max peak discharge current |
150A@1S |
/ |
| 11 |
Cooling Methode |
Nature cooled |
/ |
| 12 |
Weight |
35.4kg |
/ |
| 13 |
Battery Box Material |
Stainless Steel |
/ |
| 14 |
IP level |
IP65 |
/ |
| 15 |
Cycle life |
≥1500cycles |
25°C 0.3C/1C 70%(2%~99%SOC) |
| 16 |
Shipping Method |
50±5%SOC |
Warehouse Storage Mode |
| 17 |
Storage Time |
BMS Sleep（Warehouse Storage）：Two Months |
Charge to activate the battery from Storage Mode. |
Features
180 KM LONG RANGE
Extended range for longer daily operation.
2C PEAK DISCHARGE
High instantaneous power for stronger acceleration and climbing.
5.5 kWh HIGH CAPACITY
Large energy storage with high-density NCM technology.
HIGH-POWER OUTPUT
Built for demanding and heavy-load applications.
≥1500 CYCLES
Long-lasting performance with lower lifecycle costs.
IP65 PROTECTION
Durable stainless-steel housing for outdoor operation.
