Specification
| No. |
Item |
Parameter |
Remark |
| 1 |
Nominal Voltage |
76.8V |
|
| 2 |
Nominal Capacity |
40Ah |
|
| 3 |
Maximum continuous charge current |
20A |
|
| 4 |
Charge cut-off voltage |
87.6V |
Cell ：3.65 V |
| 5 |
Maximum continuous discharge current |
60A |
Maximum peak discharge current: 100A, 60S |
| 6 |
Discharge cut-off voltage |
64.8V |
Cell：2.7 V； |
| 7 |
Charge temperature |
0~55℃ |
|
| 8 |
Discharge temperature |
-20~60℃ |
|
| 9 |
Working humidity |
15%~90%RH |
|
| 10 |
Weight |
About 23kg |
|
| 11 |
Lifespan |
2000times |
25℃ standard charge and discharge cycle to 80% capacity, 100% DOD |
| 12 |
Battery pack size |
230×179×330mm |
|
| 13 |
Protection level |
IP67 |
|
Features
High Power Output
76.8V 40Ah configuration with strong discharge capability
Supports 60A continuous and 100A peak output for heavy-duty electric motorcycles
Smart BMS Protection System
Integrated intelligent BMS with SOC monitoring and cell balancing
Full protection against overcharge, over-discharge, overcurrent, and temperature risks
Wide Temperature Adaptability
Stable operation from -20°C to 60°C
Designed for hot climates and harsh outdoor environments
IP67 Rugged Design
Waterproof and dustproof structure
Resistant to rain, dust, vibration, and rough road conditions
Long Cycle Life & Fleet Ready
Over 2000 charge cycles for long service life
Compatible with battery swapping systems and commercial fleet applications
