Specification
| No. |
Item |
Parameters |
Remark |
| 1 |
Battery type |
LFP |
/ |
|
2 |
Working temperature |
Charging：-20～55℃
Discharge ：-30～60℃ |
Charging:-10~0℃ 10A（or 0.1C），0~5℃ 15A，＞5℃ 20A
|
| 3 |
Nominal capacity |
91Ah |
0.2C charge/0.2C discharge ，25±2℃ |
| 4 |
Configuration |
1P24S |
/ |
| 5 |
Nominal Voltage |
76.8V |
Battery Cell Voltage：3.2V |
| 6 |
Working Voltage Range |
60~86V |
/ |
| 7 |
Nominal Discharge Current |
30A |
25±2℃ |
| 8 |
Nominal Charging Current |
30A |
25±2℃ |
|
9 |
Max continuous Charging current |
125A 25°C |
High temperature rise at 2C discharge.
OTP activates after ~20 min at 25°C. |
| 10 |
Max peak discharge current |
240A@0.5S |
/ |
| 11 |
Cooling Methode |
Nature cooled |
Thermal conductive encapsulant |
| 12 |
Weight |
≤45kg |
/ |
| 13 |
Battery Box Material |
Aluminum Alloy Casing |
/ |
| 14 |
IP level |
IP67 |
/ |
| 15 |
Cycle life |
≥2500cycles |
25°C 0.3C/1C 70%(2%~99%SOC) |
| 16 |
Shipping Method |
50±5%SOC |
Warehouse Storage Mode |
| 17 |
Storage Time |
BMS Sleep（Warehouse Storage） ：Six Months |
Charge to activate the battery from Storage Mode. |
Features
Built for Long Range, Heavy Loads and Demanding Operating Conditions.
7kWh High Capacity
91Ah capacity delivers extended riding range and reduces charging frequency.
High-Power Performance
Up to 240A peak discharge supports strong acceleration, hill climbing and heavy-load operation.
≥2500 Cycles
Long cycle life helps reduce battery replacement frequency and total operating costs.
-30°C to 60°C Operation
Designed to perform reliably across a wide range of challenging climates.
IP67 + Aluminum Alloy Housing
Robust protection against dust, water and demanding outdoor environments.
